A waterfront luxury estate in South Florida. Thousands of pages of drawings, directives, and billing records. Scroll to dissect the design — sheet by sheet — the way CI reads it.

Scroll
Ground floor planGround Plan
North elevationA-201 · North
South elevationA-202 · South
East elevationA-203 · East
West elevationA-204 · West
Building section 1A-301 · Section
Building section 2A-302 · Section
Wall sectionsA-401 · Wall Sections
01 / THE SET
The permit set, opened.
Real sheets from a real waterfront build — the same documents CI ingests on day one.
02 / PLAN
One plan. Every room.
Great room, chef's kitchen, staff wing, spiral stair — and every motorized shade pocket annotated by the vendor.
03 / ELEVATIONS
Four faces of the house.
North, south, east, west — rendered elevations with every material note and finish legend intact.
04 / SECTIONS
Cut through the spine.
Building sections expose the structure — post-tensioned slabs, steel columns, the pool against the seawall.
05 / DETAIL
Down to the wall assembly.
Wall sections carry the waterproofing systems, cladding attachments, and impact ratings. CI reads all of it.
Wall section detail 42" impact glass rail · NOA #20-1211.01 ¼" Procoat XP foam cladding Tremco PUMA deck — 20-yr warranty
Every Note, Indexed

The specs live in
the margins.

The critical facts of a luxury build aren't in the pretty part of the sheet — they're in the note legends: warranty terms, impact ratings, waterproofing systems, attachment details. CI reads every legend on every sheet and indexes it to the record.

Note 202 — Slimpact postless glass rail, 42" A.F.F., large & small missile impact resistant, NOA #20-1211.01.
Note 301 — Tremco PUMA Vulkem EWS pedestrian deck system, 20-year warranty, sloped ¼" per foot.
Note 224 — Foam panels adhered to stucco, ¼" Procoat XP finish, PUMA Tamoseal waterproofing along exterior face.
Ask the Drawings

Now ask the sheets
a question.

Every answer below is drawn from the drawings you just dissected — with the citation to prove it.

CI Query Interface South Florida Estate · Active
Owner
What's the warranty on the pool-deck waterproofing?
CI · Crowncore Intelligence
20 years. The deck is specified as Tremco PUMA Vulkem EWS — a pedestrian-rated traffic system over the structural slab, sloped ¼" per foot toward the edges, over R-30 Icynene rigid insulation.
Source: A-301 Building Section · Note 301
Contractor
Are the glass rails impact rated? What do we owe the architect before fabrication?
CI · Crowncore Intelligence
Yes — Slimpact postless glass railing, 42" above finished floor, rated large- and small-missile impact resistant under NOA #20-1211.01. The note requires shop drawings and specialty engineering to be provided before fabrication.
Source: A-201 North Elevation · Note 202

This is CI's live feature set — natural-language search across full drawing sets, answered with sheet-level citations.

16
architectural sheets in this bid set alone
17
change orders logged with full approval chains
19
pay applications reviewed line-by-line
1
permanent, owner-held record of all of it

The drawings are one layer. On this build, CI also holds the RFI log, the OAC minutes, the procurement register, and every billing event — cross-referenced and queryable in plain language.

Your build deserves
this record.

CI is deployed on your project by us — your team doesn't configure anything. See it running on live project data.

Request a Demo Explore the Platform

Project identity anonymized. The drawings, notes, and record counts are real.
